Davis Vantage Pro2 ISS (Integrated Sensor Suite for Weather Station) Description Experience unmatched weather monitoring precision with the Davis Vantage Pro2 ISS Weather Station. This advanced weather station is designed to withstand the elements, providing you with years of dependable data collection thanks to its rugged, weather-proof housing.Inside the Integrated...
Vendor: Davis
SKU: 6322CM
R 23,499.00
R 23,499.00
Description

Davis Vantage Pro2 ISS (Integrated Sensor Suite for Weather Station) Description

Experience unmatched weather monitoring precision with the Davis Vantage Pro2 ISS Weather Station. This advanced weather station is designed to withstand the elements, providing you with years of dependable data collection thanks to its rugged, weather-proof housing.

Inside the Integrated Sensor Suite (ISS), you'll find a powerful combination of essential weather sensors. The outside temperature and humidity sensors are thoughtfully placed in a passive radiation shield, safeguarding them from direct sunlight and external influences, ensuring accurate readings throughout the day.

Track wind conditions in real-time with the included wind speed and direction sensors, providing you with valuable insights into the prevailing winds. The rainfall sensor accurately measures precipitation, keeping you informed about rainfall amounts for your location. Powered through the console or Gateway with battery-backup, the Davis Vantage Pro2 ISS Weather Station ensures continuous operation even during power outages. You can trust that your weather data will remain accessible and up-to-date at all times.

Setting up the Vantage Pro2 ISS Weather Station is a breeze, thanks to the included mounting hardware and easy installation process. With everything you need at your fingertips, you'll have your weather station up and running in no time. The Davis Vantage Pro2 ISS Weather Station is the epitome of reliability and accuracy, delivering precise weather data for your location. Its rugged housing guarantees years of dependable performance, while the integrated sensors offer a comprehensive view of weather conditions. With straightforward installation and versatile power options, the Vantage Pro2 ISS Weather Station is the ultimate solution for weather enthusiasts and professionals alike. Embrace the power of reliable weather monitoring and stay informed about your local climate with confidence.


Features

  • Rugged, weather-proof housing gives you years of reliable data
  • Includes outside temperature and humidity sensors in a passive radiation shield, wind speed and direction, and rainfall sensors
  • AC-powered through the console or Gateway with battery-backup
  • Easy installation with included mounting hardware

Specifications

Sensor Suite
Operating Temperature -40 to +65°C (-40 to +150°F)
Non-operating Temperature -40 to +70°C (-40 to +158°F)
Current Draw 5 mA (average) at 4 to 6 VDC for ISS only. 10 mA average for both console and ISS
Connectors, Sensor Modular RJ-11
Cable Type 4-conductor, 26 AWG
Cable Length, Anemometer 40 ft (12 m) (included), 240 ft (73 m) (maximum recommended)
Wind Speed Sensor Solid-state magnetic sensor
Wind Direction Sensor Wind vane with potentiometer
Rain Collector Type Tipping spoon, 0.01" or 0.2 mm per tip, 33.2 in² (214 cm²) collection area
Temperature Sensor Type PN Junction Silicon Diode
Relative Humidity Sensor Type Film capacitor element
Housing Material UV-resistant ABS, polypropylene
Sensor Inputs
RF Filtering RC low-pass filter on each signal line
Console
Console Operating Temperature 0 to +60°C (+32 to +140°F)
Non-Operating (Storage) Temperature -10 to +70°C (+14 to +158°F)
Current Draw 5 mA average for console only, 10 mA average for both console and ISS
AC Power Adapter 5 VDC, 1000 mA, regulated
Battery Backup 3 C-cells
Battery Life (no AC power) 1 month (approximately)
Connectors Modular RJ-11
Cable Length, Console 100 ft (30 m) (included), 1000 ft (300 m) (maximum recommended)
Housing Material UV-resistant ABS plastic
Console Display Type LCD Transflective
Display Backlight LEDs
Dimensions
Console 245 mm x 156 mm x 41 mm (9.63" x 6.125" x 1.625")
Display 151 mm x 86 mm (5.94" x 3.375")
Barometric Pressure
Resolution and Units 0.01" Hg, 0.1 mm Hg, 0.1 hPa/mb (user-selectable)
Range 16.00" to 32.50" Hg, 410 to 820 mm Hg, 540 to 1100 hPa/mb
Elevation Range -999 to +15,000 ft (-600 m to 4570 m)
Uncorrected Reading Accuracy 0.03" Hg (0.8 mm Hg, 1.0 hPa/mb) (at room temperature)
Trend Indication 5 position arrow: Rising (rapidly or slowly), Steady, or Falling (rapidly or slowly)
